NEW
AFCV20
Series
AC-DC ITE Power Module
20 Watt
Size: 2.07" x 1.08" x 0.93"
I/P: 90~305VAC
O/P:
S:5, 12, 15, 24 VDC
D:±12, ±15, 5/12 VDC
I/O Isolation: 4300VAC
Operating Temp: -40~ +85°C
KEY FEATURES
| ◆ | Ultra Compact Power Module for PCB Mountable | |||
| ◆ | Universal Input Range 90-305VAC | |||
| ◆ | Single and Dual Output | |||
| ◆ | Low No-Load Power Consumption < 0.1W | |||
| ◆ | Cooling by free air convection | |||
| ◆ | Wide Operating Temperature: -40°C~+85°C with derating | |||
| ◆ | 5000m Altitude Application | |||
| ◆ | Over-Voltage Category OVC III (New Edition) | |||
| ◆ | 5000m Altitude Application | |||
| ◆ | High Efficiency up to 87% | |||
| ◆ | Isolation Class II | |||
| ◆ | I/O Isolation: 4300VAC | |||
| ◆ | EMC Compliant without External Components | |||
| ◆ | Safety Approval to UL / IEC / EN 62368-1 | |||
| ◆ | Design meet IEC / EN 61558-1, IEC / EN 61558-2-16, IEC / EN 60335-1 | |||
| ◆ | 3-Year Product Warranty | |||
ELECTRICAL CHARACTERISTICS
| Package | Module |
| Dimensions | 52.5 x 27.5 x 23.5 mm 2.07 x 1.08 x 0.93 inches |
| No Load Power | <0.1W |
| Line Regulation | Single:±0.5% Dual:±5% |
| Load Regulation | Single:±1% Dual:±1%~±4% |
| Ripple and Noise | 5S,12S:120mV 5S12S,12D,15D:150mV 15S,24S:1% Vout |
| Agency Approvals | |
| UL / IEC / EN 62368-1 | |
| Meet | IEC / EN 61558-1, IEC / EN 61558-2-16, IEC / EN 60335-1 |
| EMI | EN 55032 Class B |
| EMS | EN 55035 |
| ■ | Please refer to the PDF file published on the web site as the final version. | |||
| ■ | We reserve the right to make alterations in the product materials and specifications without prior notification and consent to improve reliability, function or design or otherwise. | |||
