ARF240
Series
AC-DC ITE Power Supplies
available for N. America area
240 Watt
Size: 4" x 2"
I/P: 90~264VAC
O/P: 12, 24, 48 VDC
I/O Isolation: 4250VAC
Operating Temp: -40~ +80°C
KEY FEATURES
| ◆ | Enclosed / Open Frame / U Bracket Package | |||
| ◆ | Universal Input Range 90-264VAC | |||
| ◆ | Over-Voltage Category OVC III | |||
| ◆ | Low No-Load Power Consumption < 0.5W | |||
| ◆ | High Efficiency up to 94% | |||
| ◆ | Low Leakage Current < 0.75mA / 264 VAC (Touch Current) | |||
| ◆ | Wide Operating Temperature: -40°C~+80°C with derating | |||
| ◆ | I/O Isolation: 4250VAC | |||
| ◆ | Operating Altitude 5000M (OVC II) | |||
| ◆ | Active PFC Function | |||
| ◆ | Built-in 12V / 0.5A Fan Supply (ARF240O) | |||
| ◆ | Safety Approval to UL / IEC / EN 62368-1 | |||
| ◆ | 3-Year Product Warranty | |||
ELECTRICAL CHARACTERISTICS
| Package | ||
| ARF240O: | Open Frame | |
| ARF240U: | U Bracket | |
| ARF240E: | Enclosed | |
| Dimensions | ||
| ARF240O: | 101.9 x 52.1 x 27.66 mm 4.02 x 2.05 x 1.09 inches | |
| ARF240U: | 104.0 x 62.5 x 39.2 mm 4.1 x 2.46 x 1.54 inches | |
| ARF240E: | 104.0 x 62.5 x 39.2 mm 4.1 x 2.46 x 1.54 inches | |
| No Load Power | <0.5W | |
| Line Regulation | ±1% | |
| Load Regulation | ±1% | |
| Ripple and Noise | 1% Vout | |
| Agency Approvals | UL / IEC / EN 62368-1 | |
| EMI | ||
| Conducted | EN 55032 Class B | |
| Radiated | EN 55032 Class I class B / Class II class A | |
| EMS | EN 55035 | |
| ■ | Please refer to the PDF file published on the web site as the final version. | |||
| ■ | We reserve the right to make alterations in the product materials and specifications without prior notification and consent to improve reliability, function or design or otherwise. | |||
